(P/N) |
（Operating Voltage） |
（Quiescent Current） |
（Receiving distance） |
（Pin length） |
（Pin spacing） |
（Product Features） |
| DY-120WXXXXXX | 2.5-6.0V | 50-1200μA | 8-30m | 22-43 mm | 1.27/2.0/2.54mm | Anti-light interference，long distance |
| DY-120VXXXXXX | 2.5-6.0V | 50-1200μA | 8-30m | 22-43 mm | 1.27/2.0/2.54mm | Power consumption ， strong versatility |
| DY-120BXXXXXX | 2.5-6.0V | 50-1200μA | 8-30m | 22-43 mm | 1.27/2.0/2.54mm | Ultra-low power consumption,strong penetration
|
| DY-120FXXXXXX | 2.5-6.0V | 50-1200μA | 8-30m | 22-43 mm | 1.27/2.0/2.54mm | Strong anti-interference and long distance |
| DY-120AXXXXXX | 2.5-6.0V | 50-1200μA | 8-30m | 22-43 mm | 1.27/2.0/2.54mm | Narrowband decoding, anti-WiFi interference |
| DY-120XXXXXXX | 2.5-6.0V | 50-1200μA | 8-30m | 22-43 mm | 1.27/2.0/2.54mm | Continuous decoding, anti-5G interference |
| DY-120CXXXXXX | 2.5-6.0V | 50-1200μA | 8-30m | 22-43 mm | 1.27/2.0/2.54mm | Continuous decoding, strong compatibility |
